Toyota Tundra 2nd Gen 2014-2021, Westin HDX Winch Mount Modular Grille Guard, Black

A Tundra that tows and hauls into remote spots needs a front end that can take a winch and still guard the grille. The Westin HDX Winch Mount Modular Grille Guard for the 2014-2021 Tundra is a 3-piece steel guard with bolt-on headlight guards and a MAX winch tray, rated for a winch up to 12,000 lbs and 10.25in tall. The tray brackets mount to the frame and the tray is tested to a 16,500 lbs straight line pull. Drill as required, bolt it on and the Tundra gets recovery strength and front-end protection in one install.

Key Features

• 3-piece design with bolt-on headlight guards
• Uprights with 2-3/4in wide rubber push pad strips
• Winch tray brackets mount directly to the vehicle frame
• Winch trays tested to a minimum straight line pull of 16,500 lbs
• Fits medium frame 8,000 to 12,000 lbs winches up to 10.25in tall
• 2in tube full wrap-around wings
• Full punch plate grille
• Mount kit and hardware included
• Set of 2 light clamps sold separately

Specifications

• Winch depth: 6.5in
• Motor length: 7in
• Tube outside diameter: 2in
• Material: Steel
• Finish: Black powder coat
• Mounting location: Front

Fitment

• Toyota Tundra 2014-2021

Requires drilling.

In the Box

• Grille guard shell (57-923705A)
• MAX winch tray (46-22235)
• Mount kit and hardware

MPN 57-923705 · UPC 00707742118771
