Rugged Radios GMRS Mobile Radio Kit Lite w/ Stealth Antenna - 25 Watt

Go Further with our powerful, industry leading 25-watt GMRS radio kit featuring a low profile Stealth Antenna. Superior wattage provides superior power and range, giving you the ability to transmit long-distances when it matters.

Kit Features:

• GMRS 25-watt radio
• UHF Stealth Antenna
• Antenna coax cable
• 3/8" bar mount antenna bracket
• Features multiple pre-programmed channels, 8 repeater channels and 15 GMRS channels
• Easily connect to intercom, headset, or any 5-pin accessory with the built-in Rugged Ready pigtail cable!
• Loaded with channels and features, this GMR45 kit includes everything you need to start talking!

Compatibility:

• This radio works with all GMRS/FRS radios operating on the same frequencies, including but not limited to GMR45, GMR25, GMR2, and more.
• Radio Dimensions: 4-3/16"W x 5"D x 1-9/16"H
• GMRS License is required

Included:

• GMR45 Mobile Radio
• Hand mic with Scosche Magic Mount
• 3/8" bar mount antenna bracket
• UHF Stealth Antenna
• 15' antenna coax cable with 3/8" NMO mount
• Scosche Magnetic hand mic hanger
• Universal mounting bracket and hardware
• Power cable with fuse

Note: This Non Ground Plane Stealth antenna was designed for applications where a metal ground plane (such as a steel or aluminum) is not available. This design makes it perfect for mounting on a roll bar, fabricated tab, and other similar mounts. It will also work well on non-metallic roofs such as plastic or fiberglass. NOT intended for ground plane applications such as a steel or aluminum roof.

Frequency Range: 462-467MHz

Channel Capacity: 23

Channel Spacing: 12.5KHz

Frequency Stability: 2.5ppm

Operating Temperature: -10ºC~ + 60ºC

Operating Voltage: 13.6V DC ±20%

Dimension (HxWxD): 142 x 180 x 42mm

TRANSMITTER

Radio Frequency (RF) Power: 45W/5W

Frequency Modulation: 1KfF3E

Antenna Impedance: 50O

Modulation Limiting: ±2.5KHz

Modulation Distortion: < 5%

Radiated Spurious Emission: = 60dB

FM Hum & Noise: = 35dB

Adjacent Channel Power: = 60dB

RECEIVER

Reference Sensitivity: 0.35µV

Adjacent Channel Selectivity: = 60dB

Intermodulation Rejection: = 60dB

Spurious Response Rejection: = 60dB

Rated Audio Power: = 2W

Audio Response: +1` -3dB (0.3 - 2.55KHz)

Rated Audio Distortion: = 5%

FM Hum & Noise: = 35dB
