Ram 2500/3500 2019-2024, Westin HDX Winch Mount Modular Grille Guard, Black

Ram 2500 and 3500 trucks work in mud, snow and job sites where a recovery winch earns its place, and the stock front end has no mount for one. The Westin HDX Winch Mount Modular Grille Guard fits the 2019-2024 Ram 2500 and 3500 with a 3-piece steel guard and a MAX winch tray that accepts winches up to 12,000 lbs. Frame-mounted tray brackets carry the pull, tested to 16,500 lbs straight line. Trim the air dam or valance as noted, bolt the guard on and mount the winch.

Key Features

• 3-piece design with bolt-on headlight guards
• Uprights with 2-3/4in wide rubber push pad strips
• Winch tray brackets mount directly to the vehicle frame
• Winch trays tested to a minimum straight line pull of 16,500 lbs
• Fits medium frame 8,000 to 12,000 lbs winches up to 10.25in tall
• 2in tube full wrap-around wings
• Full punch plate grille
• Mount kit and hardware included
• Set of 2 light clamps sold separately

Specifications

• Winch depth: 6.75in
• Tube outside diameter: 2in
• Material: Steel
• Finish: Black powder coat
• Mounting location: Front

Fitment

• Ram 2500 2019-2024
• Ram 3500 2019-2024

Requires trimming the air dam or bumper valance. Will partially block airflow to the intercooler on EcoBoost vehicles.

In the Box

• Grille guard shell (57-924025A)
• MAX winch tray (46-24025)
• Mount kit and hardware

MPN 57-924025 · UPC 00707742118801
