Jeep Wrangler JL & Gladiator JT Oracle 7in High Powered LED Headlight, White Halo - Pair

SKU: OCL5769-001
Price
$269.10
3 In Stock
Add To Wishlist
Vehicle Fitment

2020-2023 Jeep Gladiator JT
2018-2023 Jeep Wrangler JL

Install Instructions

Install Instructions for Oracle 7in High Powered LED Headlight, White Halo - Pair - JT/JL

Warning: California Residents

WARNING: Cancer and Reproductive Harm -www.p65warnings.ca.gov

Jeep Wrangler JL & Gladiator JT Oracle 7in High Powered LED Headlight, White Halo - Pair Info & Specs

The Ultimate LED Replacement Headlight option for any vehicle with 7” Sealed Beam Lamps. The rugged design is perfect for your Jeep Wrangler, Off-Road Vehicle, Buggies, or Classic Car/ Truck. Installation is very easy with the included H4 and H13 “Plug and Play” connectors. Each set comes in full-color retail-ready packaging and a 2-Year free Replacement Warranty. You can even choose optional colored Halos for even more customization!

Latest Product Improvement:
  • Improvements in brightness and reliability by adding a constant current LED driver to the main circuit board inside of the lamp to control the halos.
  • NEW! No need for Anti-Flicker Wiring Adapters- The new SMART Integrated Can-Bus system automatically adjusts- preventing flicker issues.
  • Increased Reliability- By conditioning, the power going into the LEDs prevents degradation which can shorten the overall lifespan of the product.
  • Wider Input Voltage Range- The new SMD Halos can operate on a very wide voltage range from 12V-24V so that the voltage spike can not damage the LEDs.
  • Brighter LED Halos- by moving the heat load of the resistors off the PCB we are able to increase the number of LEDs on the circuit board without thermal issues.
  • LED chips upgraded from a Cree LED to a Phillips Luxeon ZES chip. They deliver a very high efficacy 130LM/W ratio while having a lower thermal output.
We Recommend Matching Fog Lights ORACLE Part #5846

Fit these Lights to JL or JT Wrangler ORACLE Part # 5843

Product Features: (Per Light)
  • Low Beam Wattage: 30W Normal/36W Max
  • Low Beam Lumens: 2200 Lumens/3600 Raw Lumens
  • High Beam Wattage: 40W Normal/48W Max
  • High Beam Lumens: 3600 Lumens/4800 Raw Lumens
  • Color Temperature: 6000K (Cool White Color)
  • Input Voltage of Light: 12-24V DC
  • Input Voltage of Halo (If Included): 12V DC
  • Current Draw: 2.50 Amps @ 12V DC / 1.30 Amps @ 24V DC
  • Optional: ORACLE Halo Rings Pre-Installed
  • Premium Performance Phillips Luxeon ZES LEDs
  • Die-Cast Housing with Corrosion Resistant Coating
  • Heavy Duty Solid-State Electronics
  • Hard-coated Polycarbonate Lens
  • Wide Beam Pattern with Sharp Cut-Off Line
  • Easy Plug & Play Installation
  • 2 Year Warranty
  • DOT and SAE Certified
Wiring for Halos:
  • Red Wire is (+) the positive wire
  • Black Wire is (-) the negative wire
For Halo Colors White and Amber (Road Legal Colors) we recommend:
  • Connecting wires to the Parking Light Harness
Connecting wires to Ignition Power For other Single Colors (Non Road Legal Colors) we recommend:
  • Connecting Wires to a Toggle Switch
  • Connecting Wires to a Controller
For ColorSHIFT Halos:
  • Connect wires directly to the ColorSHIFT Controller you purchased
Dimensions:
Light Diameter: 7"
Videos:
