Nissan Frontier 2022-2024, Westin HDX Winch Mount Modular Grille Guard, Black

A Frontier that heads down trails sometimes needs a pull to get back out. The Westin HDX Winch Mount Modular Grille Guard for the 2022-2024 Frontier combines a 3-piece steel guard, bolt-on headlight guards and a MAX winch tray in one front-end package. The tray holds winches up to 12,000 lbs and mounts to the vehicle frame, tested to a 16,500 lbs straight line pull. Remove the factory tow hooks, bolt on the guard and mount the winch.

Key Features

• 3-piece design with bolt-on headlight guards
• Uprights with 2-3/4in wide rubber push pad strips
• Winch tray brackets mount directly to the vehicle frame
• Winch trays tested to a minimum straight line pull of 16,500 lbs
• Fits medium frame 8,000 to 12,000 lbs winches up to 10.25in tall
• 2in tube full wrap-around wings
• Full punch plate grille
• Mount kit and hardware included
• Set of 2 light clamps sold separately

Specifications

• Winch depth: 6.75in
• Tube outside diameter: 2in
• Material: Steel
• Finish: Black powder coat
• Mounting location: Front

Fitment

• Nissan Frontier 2022-2024

Factory tow hooks cannot be reused. Not compatible with the optional Westin flush mount LED mount kit. May interfere with adaptive cruise control and parking sensors if equipped.

In the Box

• Grille guard shell (57-924075A)
• MAX winch tray (46-24075)
• Mount kit and hardware

MPN 57-924075 · UPC 00707742118658
