Ford F-250/F-350 Super Duty 2017-2022, Westin HDX Winch Mount Modular Grille Guard, Black Powder Coated

A Super Duty used for plowing, towing and recovery does better with the winch mounted to the frame instead of hanging off the bumper. The Westin HDX Winch Mount Modular Grille Guard pairs the 3-piece HDX guard with a MAX Winch Tray whose brackets bolt directly to the frame. The tray takes most medium frame winches from 8,000 to 12,000 lbs, up to 10.25in tall, and is tested to a minimum straight line pull of 16,500 lbs. Mount the tray, set the guard, and the F-250 or F-350 has a winch location behind steel wings and a punch plate grille.

Key Features

• 3-piece design with bolt-on headlight guards
• 2in tube full wraparound wings
• Full punch plate grille
• Tray brackets mount directly to the vehicle frame
• Fits most medium frame 8,000 to 12,000 lbs winches up to 10.25in tall
• Winch trays tested to a minimum straight line pull of 16,500 lbs
• Mount kit and hardware included

Specifications

• Material: Steel
• Finish: Black powder coat
• Winch depth: 6.5in
• Motor length: 7in

Fitment

• Ford F-250 Super Duty 2017-2022
• Ford F-350 Super Duty 2017-2022

In the Box

• Grille guard shell 57-923905A
• MAX Winch Tray 46-23905
• Mount kit and hardware

Notes

• For vehicles without sensors
• Excludes vehicles with the Lane Departure Distance Module if equipped
• Requires minor trimming of the tow hook pockets
• Requires trimming the air dam or bumper valance

MPN 57-923905 · UPC 00707742118627
