Ford F-150 2015-2020, Westin HDX Winch Mount Modular Grille Guard, Black Powder Coated

An F-150 on trails or work sites needs a winch that is mounted solidly, not just a guard that looks the part. The Westin HDX Winch Mount Modular Grille Guard combines the 3-piece HDX grille guard with a MAX Winch Tray. The tray brackets mount directly to the frame and hold most medium frame winches from 8,000 to 12,000 lbs, up to 10.25in tall, with a tested minimum straight line pull of 16,500 lbs. Fit the tray to the frame, set the guard around it, and the 2015-2020 F-150 has a protected place to carry a winch.

Key Features

• 3-piece design with bolt-on headlight guards
• 2in tube full wraparound wings
• Full punch plate grille
• Tray brackets mount directly to the vehicle frame
• Fits most medium frame 8,000 to 12,000 lbs winches up to 10.25in tall
• Winch trays tested to a minimum straight line pull of 16,500 lbs
• Mount kit and hardware included

Specifications

• Material: Steel
• Finish: Black powder coat
• Winch depth: 6.5in
• Motor length: 7in
• Front sensors: No

Fitment

• Ford F-150 2015-2020 (King Ranch, Lariat, Limited, Police Responder, SSV, XL, XLT)

In the Box

• Grille guard shell 57-923935A
• MAX Winch Tray 46-23835
• Mount kit and hardware

Notes

• For vehicles without sensors
• Requires drilling
• Requires trimming the air dam or bumper valance

MPN 57-923935 · UPC 00707742118610
