Dodge Ram 1500 2009-2010 & Ram 1500 2011-2018 & Ram 1500 Classic 2019-2024, Westin HDX Winch Mount Modular Grille Guard, Black

A Ram 1500 from 2009 through the 2019-2024 Classic body has plenty of life left, and a winch on the front makes trail days and work sites less risky. The Westin HDX Winch Mount Modular Grille Guard is a 3-piece steel guard with bolt-on headlight guards, a full punch plate grille and a MAX winch tray. The tray accepts winches up to 12,000 lbs and is tested to a 16,500 lbs straight line pull. Check the exclusions below, bolt the guard to the frame brackets and mount the winch.

Key Features

• 3-piece design with bolt-on headlight guards
• Uprights with 2-3/4in wide rubber push pad strips
• Winch tray brackets mount directly to the vehicle frame
• Winch trays tested to a minimum straight line pull of 16,500 lbs
• Fits medium frame 8,000 to 12,000 lbs winches up to 10.25in tall
• 2in tube full wrap-around wings
• Full punch plate grille
• Mount kit and hardware included
• Set of 2 light clamps sold separately

Specifications

• Winch depth: 6.4in
• Motor length: 6.6in
• Tube outside diameter: 2in
• Material: Steel
• Finish: Black powder coat
• Mounting location: Front

Fitment

• Dodge Ram 1500 2009-2010 (ST, SLT, Sport, Laramie, TRX, TRX4)
• Ram 1500 2011-2018 (Big Horn, Express, HFE, Laramie, Laramie Limited, Laramie Longhorn, Limited)
• Ram 1500 Classic 2019-2024 (Big Horn, Express, Lone Star, SLT, Special Service, Tradesman)

Excludes EcoDiesel engines and vehicles with plastic bumpers.

In the Box

• Grille guard shell (57-923545A)
• MAX winch tray (46-23755MAX)
• Mount kit and hardware

MPN 57-923545 · UPC 00707742118818
