Chevrolet Silverado 1500 2016-2018 & 1500 LD 2019, Westin HDX Winch Mount Modular Grille Guard, Black

On a 2016-2018 Silverado 1500 or 2019 LD, a grille guard that also holds a winch saves buying and fitting two separate parts. The Westin HDX Winch Mount Modular Grille Guard is a 3-piece steel guard with bolt-on headlight guards, a full punch plate grille and a MAX winch tray for winches up to 12,000 lbs. The tray brackets attach straight to the frame, and the tray is tested to a minimum 16,500 lbs straight line pull. Trim the air dam or valance, bolt it on and run the winch.

Key Features

• 3-piece design with bolt-on headlight guards
• Uprights with 2-3/4in wide rubber push pad strips
• Winch tray brackets mount directly to the vehicle frame
• Winch trays tested to a minimum straight line pull of 16,500 lbs
• Fits medium frame 8,000 to 12,000 lbs winches up to 10.25in tall
• 2in tube full wrap-around wings
• Full punch plate grille
• Mount kit and hardware included
• Set of 2 light clamps sold separately

Specifications

• Winch depth: 6.75in
• Motor length: 6.5in
• Tube outside diameter: 2in
• Material: Steel
• Finish: Black powder coat
• Mounting location: Front

Fitment

• Chevrolet Silverado 1500 2016-2018
• Chevrolet Silverado 1500 LD 2019

Requires trimming the air dam or bumper valance.

In the Box

• Grille guard shell (57-923875A)
• MAX winch tray (46-23875)
• Mount kit and hardware

MPN 57-923875 · UPC 00707742118795
